Application:
This machine is used for Strip and cut wire and cable full automatically.
Main Technical Data:
| Type | 8030 |
| Display | 7” colorful touch screen |
| Function | Strip and cut wire and cable full automatically |
| Applicable product | Wire, Cable, PVC |
| Stripping size | 4~30sqmm |
| Cutting length | 1mm-99999.99mm |
| Length error | 0.002*L(L=Cutting length) |
| Stripping length | Front full off: 1- 190mm, Front half off 1-1500mm |
| Rear full off: 1- 80mm, Rear half off 1-500mm | |
| Max.OD | Φ20 |
| Cutter material | imported |
| Output (time/hour) |
2000 PCS/hour(as per the wire length and size) |
| Driven type | Hybrid stepping motor and Servo knife rest |
| Feeding way | By conveyor belt |
| Remark | Can be customized as per buyer’s product |
